I Watched Experts Install XPEL Paint Protection Film Onto My 200,000 Mile Jeep And The Process Is Incredibly Difficult

Xpel Application Top
ADVERTISEMENT

As someone incapable of properly installing a screen cover onto a phone, I knew that applying XPEL Paint Protection Film (PPF) — a clear, self-healing urethane that clings onto a car’s paint and protects it for a warrantied 10 years — to a car would be challenging. What I didn’t expect was just how challenging, especially since the vehicle I planned to beat the crud out of off-road in order to test the PPF is such a basic, flat-sided Jeep Wrangler YJ. “Surely something this simple will be easy to wrap PPF around,” I thought. Here’s why I was wrong.

Thus far, The Autopian has announced its partnership with leading Paint Protection Film company XPEL, written about how unbelievably beautiful my cheap Jeep Wrangler YJ now looks since receiving PPF, and discussed why PPF makes so much sense for off-road vehicles in the first place. You should read all of those, especially that last one, because this partnership really is based on a knowledge that XPEL not only makes a great product, but also that it’s something that many car enthusiasts really would benefit from.

Vidframe Min Top
Vidframe Min Bottom

405 Motoring: PPF Application Masters

A few months back, I had my Jeep Wrangler YJ done up in the finest, thickest (10 mil, so ten times 0.001 inches = 0.01 inches) PPF that XPEL offers, called XPEL Ultimate Plus 10. The idea is that I’m going to take my Jeep off-roading through thick brush and nasty muck, and see how much more comfortable I am subjecting my paint to the elements knowing that I’ve got PPF there as protection. And ultimately, I’m going to keep track of how nice my white paint remains after many, many off-road excursions.

As shown in our YouTube video, the XPEL PPF application all went down at 405 Motoring, a premium shop in Inglewood that does detailing on some of the most most high-end machines in existence, including Lebron James’ Bronco:

ADVERTISEMENT





View this post on Instagram



A post shared by ???? (@kingjames)

That Lebron and all the owners of these high end cars put XPEL on their vehicles says a lot, but again, it’s just confirming what I’ve already heard from so many car enthusiasts: the product is legit.

The Dirt Has To Go

Screen Shot 2024 01 15 At 7.26.19 Am

ADVERTISEMENT

Before arriving at 405, I washed a bunch of mud off my Jeep YJ, though I’ll admit that I could have done a better job. You see, applying PPF requires a vehicle to be spotless. Any dirt that gets caught on the film can make application an absolute bear. Luckily, 405 has its own car wash inside the building. It’s honestly the nicest one I’ve ever seen, with a snazzy looking rotating arm and tiled flooring:

Screen Shot 2024 01 15 At 7.30.14 Am

Screen Shot 2024 01 15 At 8.14.18 Am

Once the Jeep got cleaned, 405 Motoring did a lot of work on the paint, because even though the Jeep had been repainted, it was by a guy in his garage. Remember, I only paid $7,800 for this 200,000 mile Jeep (the PPF job, 405 Motoring told me, cost about as much as my Jeep), and by the time I sold the doors and roof, I was really only in it about $6,500. It was a bargain, and the paint didn’t exactly shine, though 405 motoring fixed that with some serious detailing work. Once the Jeep was squeaky clean and the paint was shining, it entered the “Clean Room,” which you can see has a giant XPEL logo on it.

The Clean Room

Screen Shot 2024 01 15 At 7.37.56 Am

ADVERTISEMENT

The clean room is exactly what you think it is: It’s a controlled environment meant to minimize dust, dirt, or grime from affecting the PPF (and wrap) installation process. Check it out:



View this post on Instagram



A post shared by The Autopian (@theautopian)

Even after my Jeep made its way into the clean room, a tarp had to be put over the filthy engine to prevent contamination, and even more cleaning had to be done, as this Jeep was old, and had seen many, many days off-road:

Screen Shot 2024 01 15 At 8.39.15 Am

Screen Shot 2024 01 15 At 8.29.08 Am

ADVERTISEMENT

Screen Shot 2024 01 15 At 8.28.50 Am

The Trim Has To Go

In addition, a bunch of trim had to be removed, as the beauty of properly-applied XPEL is that its edges are often hidden under trim and out of sight. Unfortunately, 405 Motoring’s trim-removal guy was out, but, given that I’d pretty much installed the trim myself a few weeks prior, I made quick work of it:



View this post on Instagram



A post shared by David Tracy (@davidntracy)

Slip Solution

Doing all this work was Johnny, a PPF installation master:

Screen Shot 2024 01 15 At 8.08.19 Am

ADVERTISEMENT

Here you can see him holding some baby shampoo, which is mixed with water to create what’s called a “slip solution,” which is sprayed onto the film prior to application so that the film can “float” on painted panels as installers position it and squeeze out the solution. More on all that later.

The Design Access Program

For now, I had to ask Johnny how exactly his team figured out what size to make the film. He told me that, unfortunately, for my YJ, they had to custom-cut each piece, but this isn’t the case for most cars, as XPEL has a sweet program called “DAP.”

Xpel Dap 11 Global Increment Support

I won’t get too far into “DAP,” since XPEL experts later showed me how it works at SEMA and I’ll share that soon, but the short of it is that you can pull up a car in a drop-down menu, and literally print out the exact-size film for each panel. You can see two fenders and a hood in the image above, oriented in such a way that they’re all able to be plotted on a single piece of film.

405 Motoring’s social media guru Aalias Williams showed me the plotter (on the left side of the image below), as well as the computer they use DAP on, and a bunch of rolls of film:

ADVERTISEMENT

Screen Shot 2024 01 15 At 8.41.31 Am

It’s hard to tell in this image, but on this one piece of film, multiple pieces of PPF have been precisely cut by the plotter so that they can be removed individually and installed onto each panel:

Screen Shot 2024 01 15 At 8.46.03 Am

Of course, there was no such luck with my Jeep YJ; it’s so old and its value is so low that I bet I’m one of few people who have ever had a YJ PPF’d. As such, it was not included on DAP, meaning Johnny had to custom-cut each piece from bulk-material (I kept noticing him replacing razor blades, only to learn from him that the film was actually dulling the blade!). Typically, he’d slap the correctly-shaped film onto the special board shown below, and then moisten it, remove the film from its backing sheet, and then install the film, but instead, Johnny sized up a big piece of rectangular bulk, and put it up on the board.

Transferring The Film From ‘The Board’ To The Jeep

You can see him moistening it now as. he prepares to remove it from its backing sheet:

ADVERTISEMENT

Screen Shot 2024 01 15 At 8.55.47 Am

Here’s that removal process:

Screen Shot 2024 01 15 At 8.57.55 Am

Johnny was very careful to make sure he was able to spray all of the film:

Screen Shot 2024 01 15 At 8.57.25 Am

ADVERTISEMENT

He then sprayed down the side of my Jeep:

Screen Shot 2024 01 15 At 9.03.58 Am

And from there began the intricate “transfer” process, which in this case required a second set of hands. Basically, the transfer process means taking the film from the board, and gently placing it down onto the vehicle:

Screen Shot 2024 01 15 At 8.59.27 Am

Placing the film exactly right isn’t a huge deal, since the slip solution allows the urethane to float a bit, but there are other, tackier solutions that tend to “set” things in place, and as Johnny squeegeed the solution out, the film began to take hold:

ADVERTISEMENT

Screen Shot 2024 01 15 At 9.05.12 Am Screen Shot 2024 01 15 At 9.05.57 Am

Why Installing PPF On A Simple My Jeep Isn’t Exactly Easy

It’s an incredibly intricate process, especially when you’re doing custom-fit film like Johnny was. But the difficulty of this job goes beyond the film having to be custom fit; the Jeep Wrangler YJ is actually not an easy vehicle to apply film to, and that’s something that I wasn’t expecting. It’s such a simple design, with flat sides, and a basic, rounded hood. If you’d asked me before this experience how hard I thought applying film to a YJ would be relative to other cars, I’d have said “Probably a three on a scale of one to 10.” But that’s just wrong.

The reality is that modern aerodynamic cars lend themselves to PPF installation so much more than my old Jeep does. Take this Tesla Model Y for example:

Screen Shot 2024 01 15 At 9.16.29 Am
Image: Tesla

Just looking at it, you can imagine how easy it would be to put film on those panels. Sure, there are a few character lines that break up the “flowing” nature of the sheetmetal, and there’s that little feature on the fender, but this thing would be a very simple PPF install even if it weren’t in DAP (and it is). Meanwhile, my Johnny had to deal with this on my YJ:

Screen Shot 2024 01 15 At 9.13.40 Am

ADVERTISEMENT

See that stamped Jeep emblem in my tub? It was a bubble-trapping nightmare. Johnny showed me this cool trick where he uses a syringe to suck out the air trapped next to the letters, then he presses down with his thumb to “set” the film:

Screen Shot 2024 01 15 At 9.23.13 Am

Johnny also had all these protrusions to worry about, like the exposed door hinges, which he had to very delicately cut around.

Screen Shot 2024 01 15 At 9.12.49 Am

Watch as he uses tweezers to remove small pieces of PPF as he cuts it as close to the bracket as possible!:

ADVERTISEMENT

Screen Shot 2024 01 15 At 9.13.26 Am

All the seams between the panels aren’t ideal, either, as they require Johnny to cut the film between them in exactly the right way so that the edge of the film remains as invisible as possible. All the while, he has to make sure that he’s cutting film and not paint, and that itself is a true art:

Screen Shot 2024 01 15 At 9.49.19 Am

Johnny even showed me a trick for removing dirt that makes its way onto the film: He uses the back side of masking tape to scoop the crud out:

Screen Shot 2024 01 15 At 9.29.21 Am

ADVERTISEMENT

Throughout the job, Johnny was constantly applying slip solution, squeegeeing, adding solution, cleaning, squeegeeing, cutting, pressing with his thumb, adding solution, and on and on.

Screen Shot 2024 01 15 At 9.28.06 Am Screen Shot 2024 01 15 At 9.28.21 Am  Screen Shot 2024 01 15 At 9.30.49 Am

It’s a true art, and the way Johnny precisely cut each piece of film, folding many of them so that you never see the edge (I can’t even see the edge of the PPF on my doors and the hood) is just masterful:

Screen Shot 2024 01 15 At 9.51.24 Am

But nothing was so masterful as how Johnny applied PPF to the YJ’s rather complex grille, a surface that I didn’t even think was going to receive PPF treatment. He began by placing a roughly-sized rectangular piece of slip solution-soaked PPF onto the grille:

ADVERTISEMENT

Screen Shot 2024 01 15 At 9.54.35 Am Screen Shot 2024 01 15 At 9.54.50 Am

Then, after placing the piece where he liked it, Johnny squeezed out a bunch of solution:

Screen Shot 2024 01 15 At 9.54.58 Am

From there, he began trimming:

Screen Shot 2024 01 15 At 9.55.08 Am Screen Shot 2024 01 15 At 9.55.17 Am

ADVERTISEMENT

The most impressive part was the grille slots, where the shape of Johnny’s cut was based on the shape of the inner walls of the grille slats that he would be folding the PPF onto:

Screen Shot 2024 01 15 At 9.55.50 Am Screen Shot 2024 01 15 At 9.56.01 Am

It’s Beautiful Peace-Of-Mind

The results are just amazing:

Screen Shot 2024 01 15 At 10.00.19 Am

Not only has the car been detailed, but the PPF adds this almost candy-like clearcoat effect, making the thing just pop. Aside from that lovely effect, it’s hard to tell that there’s any coating on there at all — it’s all just so well hidden and tucked and folded. Like I said, masterful:

ADVERTISEMENT

Screen Shot 2024 01 15 At 10.00.03 Am

I just took my Jeep off-roading this past weekend, and believe me when I say: I beat the crap out of this Jeep. And you know what? I wasn’t worried at all about that gorgeous paint getting scraped up:

Screen Shot 2024 01 15 At 9.39.22 Am

And that’s a good thing, as I had other things to worry about:

Screen Shot 2024 01 15 At 10.04.45 Am
