My recent hospital stay exposed me to a number of things that have eluded me in my normal, non-hospital-based life, most notably bottles that you can pee in while in bed without everyone calling you lazy and disgusting, and also modern hospital beds. It’s the hospital bed that I’d like to discuss now, because the modern hospital bed I was in, a Hillrom Centrella, utilizes a certain kind of lighting technology that I’d previously only seen in the mass market on premium cars and SUVs — but the bed uses the tech for a very different purpose and context. I’ll explain.

First, I should note that the Centrella may very well be the most advanced bed I’ve ever had the pleasure of dampening. It’s a remarkable machine, capable of keeping my aching body in multiple comfortable positions while simultaneously monitoring various aspects of my well-being, and being ready to alert the nursing staff should I have decided to make a break for it.

Vidframe Min Top
Vidframe Min Bottom

Usbspeaker

I mean, this thing had everything: a USB charging port, integrated speakers connected to the wall-mounted television, powered casters for transport, full articulation, sensors all over the place and so much more. A technological tour-de-force that I slept on, and, I’m not proud to say, soiled on more than one occasion. (I was in ICU, cut me some slack!)

One of the most notable things the Centrella had, the feature most likely to be commented on by people who came to visit me, was this:

ADVERTISEMENT

Bed Lights

See those projected images on the floor by the bed? Those are part of the SafeView+ system, designed to let caregivers see some basic status information about the bed at a glance, from a distance, without having to, say, get all the way up to the bed and peer at some little screen.

It’s extremely clever, and if you’re curious, those icons tell, from left to right, the bed side rail condition, the bed exit alert status, and the right one tells that the bed is in its lowest position.

Safeview

Now, to a car person, these sorts of images projected on the ground are actually quite familiar, as they have been a staple of premium cars and SUVs for nearly a decade or so now, and we call them “puddle lamps.”

ADVERTISEMENT

Mustang Otto

There’s a puddle lamp on a Mustang, being admired by my son Otto when he was, jeez, like nine years younger. These use the exact same simple and bright projector technology as the Centrella SafeView+ projection system, though an informal conversation with a Hillrom representative revealed that the engineers on the Centrella project were not inspired by the automotive puddle lights, though if they were it sure would make this story a lot better for a car website like ours.

Still, that’s not going to stop me, because I still think what is going on here is pretty cool: we have the same fundamental technology, but used in wildly different context and for purposes that are about as removed from one another as possible.

In the automotive world, this technology is used to broadcast to people in the vicinity of your car, at night, that you’re a person of refinement and taste who was more than happy to throw around a few extra bucks to get exciting light shows like this every time you approach your car:

ADVERTISEMENT

And in the case of the Centrella bed, this lets a passing nurse know at a glance if there’s an alarm set in case you try to sneak out of bed, like some kind of miscreant with tubes connected to your abdomen.

These really couldn’t be more different applications for the same project-a-bright-image-on-the-ground tech, and yet here we are, in the unexpected and beautiful convergence of fancy car and hospital bed tech.

You want to know another little detail I liked on the Centrella? It was this indicator of bed angle:

Angleball

I like that it’s indicated with that little metal ball instead of some LED-based indicator I would have expected. I’m not sure why it’s done this way, and I suspect there must be a good reason – perhaps so this can still be read in unpowered situations? But there’s something quite satisfying about it.

ADVERTISEMENT

Also, that indicator with the two down arrow buttons forms a sort of sassy face, which was a big help keeping one company on those lonely nights in the ICU. Miss you, Sassybedface!

[Ed Note: Not to hijack Jason’s blog, but I’d like to note another medical-auto industry crossover: The pressure sensitive mat! Check this out:

Screen Shot 2024 01 05 At 2.28.55 Pm

I remember seeing a “pressure sensing floor mat” like the one above when I visited my Oma at a nursing home during her final days on this planet. Here’s a description of what it’s for, via Val-U-Care:

Quiet, Wireless and Cordless – Pressure Sensing Floor Mat 24″x48″ by Smart Caregiver (PTFM-07C, Gray) works with wireless and cordless fall prevention monitors, place next to a bed or in a door way to monitor a resident getting up or leaving a room.

It’s all about monitoring vulnerable people and attending to them if they leave when they shouldn’t or if they fall out of bed. It works in a similar way to this “pressure-sensitive safety mat” similar to the one I stepped on when I was an intern visiting Jeep’s Jefferson North Assembly Plant (where they build the Grand Cherokee), thereby shutting down the entire assembly line (I got chewed out! Every few seconds of down-time cost the company thousands!):

ADVERTISEMENT

Screen Shot 2024 01 05 At 2.27.10 Pm

Here’s the description of its purpose, via Rockford Systems, LLC:

Pressure-sensitive safety mats are intended to be used as auxiliary or additional safeguarding equipment to protect operators and other employees in the machine area. They must not be used as primary safeguarding except when all other means are not applicable.

These mats can safeguard many types of machines. When considering their use, the following should be asked:

  1. How is the mat to be interfaced to the existing motor control or equipment? Does a new control or starter need to be added?
  2. Can the motion of the machine that is creating the point-of-operation hazard be stopped quickly? If it can, what kind of clutch and brake arrangement does it have? Is the machine hydraulically or pneumatically operated? Is it operated by any other means?

Anyway, there’s lots of crossover between the medical and auto fields, apparently! -DT]
