Ford Recalled The Transit Trail And The Fix Is Taking The Trail Part Out

Ford Transit Trail Tire Rub 2ts
ADVERTISEMENT

Back in late 2022, Ford capitalized on the movement of DIY camper van builds with the release of the Transit Trail. The van is supposed to take care of most of the hard work from the lift kit and knobby tires to all-wheel-drive, a roof fan, and basic wiring. As it turns out, some of those goodies aren’t working out so well. Ford has issued a recall because the tires can rub on the van’s body. The fix is disappointing, as are the issues owners are reporting.

This is a pretty big deal because the Ford Transit Trail is marketed as the roomy van to make RV conversions easier for DIYers and RV manufacturers alike. The pandemic changed the RV landscape as more Americans began hitting the road in camper vans rather than gigantic Class A motorhomes. At the same time, the vanlife movement also took off, with more adventurous Americans looking to build their own little homes on wheels.

Vidframe Min Top
Vidframe Min Bottom

The Ford Transit Trail was designed to cater to those who want to craft their own van and sleep by a secluded lake. There’s a lot involved in building your own camper van. If you start with a plain work van, you have to bust out cutting tools to slice a hole in your roof to fit an air-conditioner or roof fan. If you want that van to go off-road, now you have to handle the lift kit, tires, and underbody protection. Oh, and you better hope you didn’t choose a rear-wheel-drive van because now you have to convert that to 4×4, too.

That’s where the Transit Trail comes in. The Ford Pro division, through its third-party upfitters, takes AWD Transits, gives them a lift, all-terrain tires, and sets up a basic electrical system including a second 12V battery so builders have fewer headaches. If you’re afraid of cutting a hole into your $65,000 van, I get it. So, Ford Pro’s upfitter can do it for you and fill the hole with a Maxxfan RV ceiling fan. Here are a few paragraphs from when I got to see the Transit Trail in person:

ADVERTISEMENT

The Transit Trail comes equipped with bespoke 16-inch alloy wheels painted in black. These are the same wheels as found on the UK version, but now we know more about them. These wheels are wider and with a different offset than regular Transit wheels, resulting in a 2.75-inch-wider track over a base Transit. Those wheels are wrapped in 30.5-inch Goodyear Wrangler Workhorse all-terrain tires. Ford says that these tires have a 2.5-inch larger diameter than standard Transit tires.

This tire package is combined with a 2.25-inch suspension lift. Ford says that its engineers didn’t just lift it and call it a day, but the Transit’s unibody was reinforced in certain areas to deal with the lift. The Transit Trail also gains a new steering column to help maintain geometry. And further changes were made to the sheet metal to accommodate the changes to the steering. Ford’s goal was to lift the Transit without doing anything that would wear out driveline components faster than they normally would.

All of this adds to 6.7 inches of ground clearance at the Transit Trail’s lowest point. Approach angle is 19.5 degrees, Departure 25.3, and breakover 19.3. These wouldn’t be amazing numbers for a 4×4 SUV, but remember, this is the kind of van that your plumber would normally drive.

We’ve already seen some cool Transit Trail-based builds, including the Thor Motor Coach Talavera:

In March, Ford issued a recall on select Transit Trail vans. According to the recall, the off-road tires installed onto the Transit Trail may make contact with the van’s body:

Due to insufficient packaging allowance, the front tires may contact the front wheel arch liner and body flange under certain vehicle loading, steering angle, and braking conditions. Repeated contact of a front tire with the wheel arch liner and body flange may lead to rapid air loss and tread-belt separation, which can result in a loss of vehicle control and increase the risk of a crash.

Ford Engineering demonstrated that the shoulder area of the front tires can contact the wheel arch liners at 60% of full turn while braking, when the vehicle is loaded at or near the vehicle’s Front Gross Axle Weight Rating (FGAWR).

ADVERTISEMENT

Thankfully, no incidents have been tied to this issue, but the recall notice notes that seven VINs have been recorded to have tire rubbing problems. Likewise, a root cause has not been established. First discovered by the Drive is the remedy. Ford will change out the tires on the affected vehicles.

The 30.5-inch 245/75R16 Goodyear Wrangler Workhorse AT tires that come on the Transit Trail will be swapped down to 28-inch 235/65R16 tires of unknown type and origin. This is notable because this tire size is the same size that you get with the Goodyears on a regular Transit. So, the fix is essentially to downgrade one of the biggest selling points of the Transit Trail.

Some digging by owners reveals that the issue appears to be clearance between the tires and the van’s pinch seams in the wheel wells. Under braking and cornering, the bigger tires can make contact. A workaround some have suggested is to fold over the pinch seams for more clearance.

Perhaps the weirdest part of the recall is that not every Transit Trail is expected to be hit. The recall says 1,902 vans are potentially involved and 25 percent of the vans are expected to have the tire clearance defect. It goes on to say that the defect impacts Transit Trails built from March 2022, before the van was announced in America, to March 2024. It’s unclear whether Transit Trails built after March all come with the downgraded tires or if the error from the upfitter will have been corrected.

ADVERTISEMENT

The tire change drops the lowest point ground clearance to 5.5 inches. Ford Pro has not published adjusted ramp angles for the recalled vans, but they won’t get any better. As it is, the Transit Trail already had worse angles and clearance than the AWD version of the Mercedes-Benz Sprinter. That van has 8 inches of ground clearance plus 26-degree approach, 25-degree departure, and 23-degree breakover angles, respectively.

So, what does this leave affected owners? Well, they still get the aggressive body cladding, the sort of Raptor-inspired grille, a 6,500-pound tow rating, the lift kit, the electrical system, and the unique wheels. Some might get away with aftermarket tires, but they will also likely run into the rubbing issue. That also leaves you with the “skid plate-style” front bumper. Yep, what looks like a skid plate up front is a piece of plastic. The rock slider-style steps are also more for show.

Some owners have been reporting issues with the optional roof fan install, including water leaks through the bolts. One person received a new Transit Trail with rust spots on its roof, bubbling interior paint, and a fan install that looks worse than a new RV out of Indiana.

As I said before, the Transit Trail is supposed to be Ford’s answer to easier camper van builds. However, the tire recall and potential upfitter quality problems may turn some buyers away. We also want to know if the small tires are here to stay and what kind of tires buyers will be getting moving forward. We’ve reached out to Ford for comment on these issues and more and will update when we hear back.
